• Driver Configuration

Reading, loading, and saving of driver parameters.

Different drivers can be connected via a USB hub, and specific drivers can be selected and controlled simultaneously through Caliper. Equipped with an oscilloscope with 4 configurable channels, with the possibility to register, save, and print the measures taken.

Automatic motor tuning and automatic phasing.

Selection and configuration of operating modes:

   Torque control

   Limited torque control

   Speed and position control

   Multi-segment position control

   Electronic axis

   Electronic cam

   Pressure control (hydraulic press)

   Filter

   Display alarms.
